| Machine: |
Semi Automatic Linear High Speed 12 Stations (Single Hopper Single Nozzle)
Lami/Plastic/Aluminum Tube Filling, Sealing And Coding Machine. |
| Model: |
ABBAX-35 |
| Product, To Fill & Seal: |
Oinments,Creams,Honey,Balms,Pastesetc |
| Respect to tube Dia. & tube height maximum: |
Tube Diameter max. 40mm, & Tube height max. 200mm. |
| Filling device: |
Positive suction & displacement PISTON type |
| Filler Pump: |
(5 Gms. to 30 Gms.) or (30 Gms.to 100 Gms.) or (100 Gms. to 250 Gms.) Any one of the three sets will be provided against requested specification in your order. |
| Filling Capacity: |
Machine is suitable for 5 gms to 200 gms with inter changeable filler piston pump. |
| Product , Contact Part: |
Stainless Steel 304 or 316 grade |
| Hopper: |
45 Kg capacity(Working Volume 40 Kg). |
| Filling Volume setting: |
Cam for Valve operation as well Fine Tuning adjustable Control System. |
| No tube - No Fill Device: |
Activate Sensor with Electrical Logic Control system. |
| Filling Accuracy: |
± 1%. |
| Output per Minute: |
Up to 35 Tubes/ Min. In Single Hopper One Nozzle (depending on the Fill sizes). |
| Indexing Device of Turret: |
Manifold Indexer unit |
| Empty Tube in feeder: |
Manual |
| Change Part : |
Piston Pump Housing of 30gms to 100 gms, , Tube Holder Cups, Filling Nozzle, |
| Tube Orientation Device: |
Top Drive (Photocell Unit) Make Std. and Stepper Motor & ‘I’ Mark Sensor DETALOGIC Make. At the separate station. |
| Aluminium Tube Crimping Unit |
Pneumatic Operated- Festo-Germany Make |
| Folding Unit |
2-3 Folds as desired ,Pneumatics operated-Festo-Germany Make |
| Trimming device: |
NA |
| Tube ejection: |
Automatic Filled Tube ejection at separate station. |
| Machine System Description: |
Manual Tube Feeding, ‘I’ Mark Orientation, Filling, Crimping, Batch Coding and filled Tube Ejector Automatically. |
| Machine security: |
Overload clutch for centering and micro switch cut-off system. |
| Control Panel: |
Necessary functional features like emergency stop, re-set, inching, and user friendly, Electrical logic system are standard with the machine, with interlock & indication on the main operator’s of panel to Electrical logic Control. |
| Motor: |
1. HP; 1440 RPM 3Ph. 440V AC. Standard Make |
| Production Speed Control |
Variable speed control Suitable VFD Drive makes DELTA. |
| Production Counter: |
Digital Six Digit Production Counter. |
| Gear Box: |
Suitable Gear Box Ratio 30-1 Make PREMIUM/P.G. Drive with Separate Drive. |
| Production Counter: |
Activate Sensor with Electrical Logic Display 6 mm. Size, 6 Digital Counter. |
| All Pneumatic components: |
FESTO-GERMANY Make. |
| Machine Entire frame: |
Fabricated in Machine Entire frame Mild Steel With Powder Coated &will be in hard Chrome plated & duly ENP coated and all othercams and levers will be in graded casting & alloy steel. With all side covers in S.S.-304. |
| Power Input: |
1KW |
| M/c. Dimensions : |
(L) 900 x (W) 1200mm x (H) 2450mm. |
| M/c. WeightApprox: |
Overall Wt. Approx. 500 Kgs. |
