| Machine: |
Fully Automatic Linear High Speed 12 Stations (Single Hopper Single Nozzle)
Tube In Feeder Cassette Device Attached Lami/Plastic/ Aluminum Tube Filling, Sealing And Coding Machine. |
| Model: |
ABBAX-60 |
| Product, To Fill & Seal: |
Ointment / Cream into the Lami/Plastic Tube |
| Respect to tube Dia. & tube height maximum: |
Tube Diameter max. 40mm, & Tube height max. 200mm. |
| Filling device: |
Positive suction & displacement complete SS-316. After each filling session a control on tailing is achieved by a pneumatic cut-off system, along with filters, that cleans the nozzle of the excess sample. |
| Syringe Pump Insert for Filling: |
(5 Gms. to 30 Gms.) or (30 Gms.to 100 Gms.) or (100 Gms. to 200 Gms.) Any one of the three sets will be provided against requested specification in your order. |
| Filling Capacity: |
Machine is suitable for 5 gms to 200 gms with inter changeable Syringe pump. |
| Product , Contact Part: |
S.S-316. |
| Hopper: |
Hopper of 60 Kg capacity(Working Volume 52 Kg). |
| Filling Volume setting: |
Cam for Valve operation as well Fine Tuning adjustable Control System. |
| No tube - No Fill Device: |
Activate Sensor with Electrical Logic Control system. |
| Filling Accuracy: |
± 1%. |
| Output per Minute: |
Up to 60 Tubes/ Min. In Single Hopper Two Nozzle (depending on the Fill sizes). |
| Indexing Device: |
Indexer Manifold . |
| Auto tube in feeder: |
Cassette Device System with Four Cassettes One Tube Size will be provided. |
| Change Part : |
Syringe Pump Housing of 30gms to 100 gms, Two Cassettes , Tilting Cam, Feeding Con, Holder, Filling Nozzle, and Heating Adopter, of Removable type suitable for any one-size of tubes. With basic machine. will be provided |
| Tube Orientation Device: |
Top Drive (Photocell Unit) Make Std. and Stepper Motor & ‘I’ Mark Sensor DETALOGIC Make. At the separate station. |
| Lami / plastic tube heating device: |
LEISTER or BAK Swiss Make, with suitable for Blower 0.35 HP. BLOWTECH Make. And hot air tool adopter jacketed water cooling systemAttached,at the separate station. At the separate station. |
| Lami / Plastic Tube Sealing Device: |
Pneumatics operated. Jacketed water cooling System Attached, In sealing & coding where in the tube is pressed & sealed and then batch coded. With metal stereos coding Letter punch (female type 0 to 9, one set). At the separate station. |
| Trimming device: |
Pneumatics operated. At the separate station. |
| Tube ejection: |
Automatic Filled Tube ejection at separate station. |
| Machine System Description: |
Empty Tube Feeding, ‘I’ Mark Orientation, Filling, Sealing, Crimping, Coding and filled Tube Ejector Automatically. |
| Machine security: |
Overload clutch for centering and micro switch cut-off system. |
| Control Panel: |
Necessary functional features like emergency stop, re-set, inching, and user friendly, Electrical logic system are standard with the machine, with interlock & indication on the main operator’s of panel to Electrical logic Control. |
| Motor: |
1.5 HP; 1440 RPM 3Ph. 440V AC. Hindustan Make. |
| Gear Box: |
Suitable Gear Box Ratio 30-1 Make PREMIUM with Separate Drive. |
| Production speed control: |
Variable speed control Suitable VFD Drive makes DELTA. |
| Production Counter: |
Activate Sensor with Electrical Logic Display 6 mm. Size, 6 Digital Counter. |
| All Pneumatic components: |
FESTO Germany Make. |
| Machine Entire frame: |
Fabricated in Machine Entire frame Mild Steel With Powder Coated &will be in hard Chrome plated & duly ENP coated and all othercams and levers will be in graded casting & alloy steel. With all side covers in S.S.-304. |
| Power Input: |
2-5 kW. 3 phase. |
| M/c. Dimensions : |
(L) 2640mm x (W) 1080mm x (H) 2450mm. |
| M/c. WeightApprox: |
Overall Wt. Approx. 1200 Kgs. |
